Magnetic Level Gauge Product

Product Category: Industrial automation

Save the product

Product Introduction

Magnetic flap level gauge is a local level measuring instrument based on magnetic coupling principle. It can directly display the liquid level height inside containers, widely used in petroleum, chemical, water treatment, pharmaceutical and other industries.The instrument consists of main chamber, magnetic float and magnetic indicator assembly. As liquid level changes, the magnetic float moves up and down. The permanent magnet inside float drives the external flaps via magnetic coupling. Flaps switch between red and white: red for liquid present, white for empty, realizing on‑site visual level indication.It can be equipped with level switches and 4‑20mA remote transmitter for level alarm and remote signal output. Multiple materials are available including 304 / 316L stainless steel, PP, PVC, suitable for high‑temperature, high‑pressure and corrosive media.

Product Brochure
