SHANDONG LINGSHENG HEAVY INDUSTRY MACHINERY CO., LTD.

SNIEC E6.131

Headquarters:

Target Groups:

Concave, Mantle and Bowl liner

Product Category: Linings for crushers, mills, etc.

Save the product

Product Introduction

Cone crusher wear parts — concave, mantle and bowl liner — cast to your drawing or to a worn sample. Material: manganese steel Mn18Cr2, solution treated; high-chrome iron or composite grades for secondary and tertiary duty where abrasion dominates. Cavity: profiles are designed separately for coarse, medium and fine crushing, so the feed opening and the closed-side setting match the machine. A cavity that is close but not correct is the usual reason output drops and flakiness rises. The backing face is machined to the cone contour and used with an epoxy backing compound, which closes the gap between liner and cone and stops the liner working loose or spinning. Inspection: chemical composition, hardness, cavity dimensions and wall thickness per lot. Minimum order one set. Quotation within 24 hours of a drawing. Every shipment carries a heat certificate, hardness report, dimensional report and certificate of conformity.
